用途：适用于家电玻璃、洗衣机、圆形玻璃等印刷。

Application: Suitable for printing household glass, washing machine, round glass, etc.

特点：

1. 上片、精准定位、印刷、卸片全自动运行，易于操作，保证品质。

2. 精定位采用伺服电机配合高精度直线导轨，精度高。

3. 印采用采用伺服电机，精度高确保印刷产品质量稳定，印刷物均匀无波浪状。

4. 玻璃搬运到印刷平台，采用伺服电机梭子穿梭式结构，速度快精度高。

5. 网版升降采用伺服电机，配合直线导轨上下移动，精度高速度快。

6. 控制系统采用进口 PLC 可编写控制系统和人机界面。

7. 本机设有自动报警装置及周边安全保护开关，并可选择配置气动机械安全保护装置，确保安全生产。

Features:

1. Loading, accurate positioning, printing, unloading automatic operation, easy operation, quality assurance.

2. Precise positioning using servo motor with high precision linear guide rail, high precision.

3. Printing adopts servo motor with high precision to ensure stable quality of printing products and uniform printing without wavy shape.

4. The glass is transported to the printing platform with servo motor shuttle structure, which has high speed and high precision.

5. Screen lifting adopts servo motor, with linear guide rail moving up and down, high precision and fast speed.

6. The control system adopts imported PLC which can write the control system and man-machine interface.

7. The machine is equipped with automatic alarm device and peripheral safety protection switch, and optional pneumatic mechanical  safety protection device, to ensure safe production.
